How to Choose the Right Mountain Bike Size for Your Height

You can have the best components in the world, but if the frame is the wrong size, every ride will feel a little off. Too big and the bike feels stretched and hard to control. Too small and your knees, back and wrists take the hit. The good news: finding your size is easier than it looks.

Start with your height

Your height is the quickest guide to frame size. For our 29" mountain bikes, this is where most riders land:

• Small (S): 5'2" to 5'6"
• Medium (M): 5'6" to 5'10"
• Large (L): 5'10" to 6'2"

Every Fittrip bike lists these ranges in the size guide and the Geometry section on the product page, so you can check before you buy.

Then check your inseam

Two people of the same height can have very different leg lengths. Stand barefoot against a wall, put a hardcover book between your legs (spine up, snug like a saddle) and measure from the top of the book to the floor. That is your inseam.

Compare it to the bike's standover height, the height of the top tube where you stand over the bike. You want at least 2 to 5 cm of clearance on a mountain bike, so you can hop off quickly on rough ground.

The geometry numbers that matter

• Seat tube length: decides how low the saddle can go. Shorter is better if you like to drop the seat on descents.
• Effective top tube: how stretched out you feel. Longer gives stability at speed; shorter feels more upright and playful.
• Wheelbase: the distance between the axles. A longer wheelbase feels calm and planted; a shorter one turns faster.
• Head tube angle: a slacker angle (lower number) feels more stable downhill, a steeper angle steers quicker on climbs.

Between two sizes?

It happens a lot. A simple rule: size down for control, size up for stability. If you ride tight, twisty trails and like to throw the bike around, go smaller. If you mostly ride fast fire roads or long distances, go bigger.

Fine-tune the fit at home

1. Saddle height: with your heel on the pedal at the bottom of the stroke, your leg should be almost straight. When you pedal normally, you get a slight bend at the knee.
2. Saddle position: slide it forward or back so your knee sits roughly over the pedal axle when the crank is level.
3. Handlebar reach: you should reach the grips with a relaxed bend in your elbows. If you feel stretched, a shorter stem helps.

The bottom line

Use your height to pick a size, confirm it with your inseam and standover height, then dial in the saddle and bars. A bike that fits is more comfortable, more efficient and a lot more fun. Still unsure? Reach out to our team with your height and inseam, and we will point you to the right frame.
